Creating a Replica

This step is required to take maps offline and allow the map configured in CoreVision to be available in FieldVision with full interactability. By creating a replica, the data can be downloaded, used in the field without connectivity, and later synchronized back into the enterprise database.

Note: Replicas must be created in the SQLite (file geodatabase) format to preserve GlobalIDs, relationships, and attachments for FieldVision workflows.

ITpipes is more than willing to assist with this process - we can create the replica and update your organization with the results. We can verify a successful replica and provide support if troubleshooting is required.

Replica Settings

• Replica Name: Test
• Layers: (e.g., 0, 1, 2)
• Geometry: Add the full extent, separating each axis with commas (e.g., xMin,yMin,xMax,yMax).
• Input Spatial Reference and Replica Spatial Reference: Enter the spatial reference from the feature service (e.g., 102100).
• Return Attachments: False
• Create Replica Asynchronously: True
• Sync Model: None
• Target Type: Client
• Sync Direction: Bidirectional
• Attachments Sync Direction: None
• Data Format: sqlite



Executing the Replica

1. Select the Create Replica button.
2. Once the Status URL appears, copy it and open it in a new tab or window.
3. Refresh the page until a successful replica is created.

Resources

• https://pro.arcgis.com/en/pro-app/3.3/tool-reference/data-management/create-replica.htm
• https://support.esri.com/en-us/knowledge-base/how-to-download-and-extract-a-hosted-feature-layer-with-000012232
